HDPE Plastic Melting Point: Temperature Analysis

Reviewed and updated by ICD - Week 37/2026

HDPE melts at 120-135 degrees C (248-275 degrees F) for standard homopolymer grades. This melting point - significantly lower than engineering plastics but higher than LDPE and many other commodity plastics - defines where HDPE can and cannot be used in high-temperature environments.

What is the melting point of HDPE?

HDPE (High-Density Polyethylene) is a semi-crystalline thermoplastic. Its “melting point” is technically a melting range rather than a single temperature, because:

• Crystalline regions in HDPE melt over a range of ~120-135 degrees C
• The amorphous regions soften at lower temperatures (starting around 80-90 degrees C)
• Different HDPE grades (homopolymer vs copolymer, different MW) have slightly different melting ranges

For practical engineering purposes: HDPE structural integrity is lost above ~120 degrees C. Between 82-120 degrees C, HDPE softens and deforms under load but does not flow freely.

HDPE temperature thresholds

HDPE melting point vs other plastics

Why does the melting point matter for HDPE applications?

For HDPE pallets: The 82 degrees C continuous service limit - well below the melting point - is the relevant threshold for warehouse use. In tropical countries with metal-roof warehouses, floor temperatures can reach 45-55 degrees C in extreme conditions - still well within HDPE’s safe service range. Autoclaving or steam sterilization (121-134 degrees C) exceeds HDPE’s melting point - do NOT autoclave standard HDPE pallets (use PP for autoclave environments).

For HDPE pipes: PE100 pressure pipes are rated for continuous service at 20 degrees C (maximum pressure) and de-rated at higher temperatures per ISO 4427. At 60 degrees C, the pressure rating is approximately 50% of the 20 degrees C rating. Hot water systems above 60 degrees C require polypropylene or CPVC pipes.

For food containers: HDPE food containers are not microwave-rated because microwave heating can locally exceed 82-100 degrees C. Use PP (code 5) containers for microwave heating.

To understand how the resin is produced before it reaches this melting stage, see PE plastic manufacturing process: two core methods.

Frequently Asked Questions

1. At what temperature does HDPE start to soften?

HDPE begins to soften (lose stiffness) above its glass transition temperature (Tg around -100 degrees C for PE) but more practically above its HDT of 60-80 degrees C. Significant softening and deformation under load occurs above 82 degrees C. Full melting occurs at 120-135 degrees C.

2. Can HDPE withstand boiling water (100 degrees C)?

HDPE’s melting point (120-135 degrees C) is above 100 degrees C, so it does not melt in contact with boiling water. However, its continuous service limit is 82 degrees C, and sustained immersion in boiling water will cause softening and deformation. Short-term contact with boiling water (a few seconds) is generally tolerated; sustained hot water contact is not recommended.

3. Why is PP’s melting point higher than HDPE’s?

PP homopolymer melts at 160-168 degrees C vs HDPE’s 120-135 degrees C. The difference comes from their backbone chemistry: PP has a methyl side group on every other carbon, creating a more ordered crystal structure that requires more energy (higher temperature) to disrupt. HDPE’s simpler linear chain structure, while highly crystalline, has weaker van der Waals forces between chains.

Melting point vs softening point of HDPE

HDPE has two distinct thermal thresholds that are often confused. The softening point - around 120-130 degrees C (Vicat) - is where HDPE begins to deform under a standardized load but still holds its shape. The melting point of 125-135 degrees C is where the crystalline regions fully melt and the polymer flows. For load-bearing use such as HDPE pallets, neither figure is the working limit: the continuous service temperature of 82 degrees C is what matters, because HDPE loses stiffness well before it melts.

The processing temperature is always set 50-100 degrees C above the melting point so the melt flows evenly into the mould or die. For HDPE, extrusion and injection moulding run at 180-240 degrees C - high enough for full flow, low enough to stay clear of thermal degradation that starts above 300 degrees C. Running too cold traps air and weak welds; running too hot risks burning and brittle parts. This processing window is one reason HDPE is among the most cost-effective plastics to form, and why ICD Vietnam uses it for durable HDPE plastic pallets. For technical specifications, call ICD Vietnam on 0983 797 186.

Reference

Melting point of HDPE plastic - Society of Plastics Engineers (SPE).
