The ICD Spill-Containment Pallet 4-Drum measures 1300 x 1300 x 300 mm. Colors: orange, purple, black, grey, green, yellow, blue, red. It weighs 30 kg. It has a static load of 2,000 kg and a dynamic load of 1,000 kg. Material: HDPE (black version: recycled plastic).
1. Specifications of the ICD Spill-Containment Pallet 4-Drum
| Specification | Details |
|---|---|
| Product code | ICD-PCT-4P-130130030 |
| Dimensions | 1300 x 1300 x 300 mm |
| Static load | 2,000 kg |
| Dynamic load | 1,000 kg |
| Racking load | Not published by ICD |
| Weight | 30 kg |
| Material | HDPE (black version: recycled plastic) |
| Color | Orange, Purple, Black, Grey, Green, Yellow, Blue, Red |
2. How to Read the Load Ratings of This Pallet
Under ISO 8611, static load is the mass a pallet carries when it rests on a flat floor (2,000 kg for this code); dynamic load is the mass it carries while a forklift or hand pallet truck moves it, so the figure is lower (1,000 kg); ICD has not published a racking load for this code. The full definitions are on the ISO 8611-1 standard page. If the pallet will go on a racking, ask ICD before ordering rather than inferring a racking load from the static figure.
One pallet covers 1.69 m² of floor, so a layer of 100 pallets covers about 169 m².
Browse the full Spill-Containment Pallets range from ICD Vietnam.
3. Comparison with Other 1300x1300 mm Pallets from ICD
The table lists ICD pallets with the same 1300x1300 mm footprint and the figures ICD has published. "Not published" means the product page has no figure.
| Product code | Height | Static load | Dynamic load | Weight |
|---|---|---|---|---|
| ICD-PCT-4P-130130030 (this page) | 300 mm | 2,000 kg | 1,000 kg | 30 kg |
| EN4-1313 MS Plastics | 150 mm | 4,000 kg | 1,000 kg | 21 kg |
4. Product Images
5. Frequently Asked Questions
How many kg can the ICD-PCT-4P-130130030 carry?
ICD publishes a static load of 2,000 kg and a dynamic load of 1,000 kg. ICD has not published a racking load for this code, so ask ICD first if you plan to use a rack.
How much does the ICD-PCT-4P-130130030 weigh?
It weighs 30 kg according to the specification ICD publishes.
Can I order a specific color or print a logo?
ICD lists these colors for this code: orange, purple, black, grey, green, yellow, blue, red. Please contact ICD for the conditions.
