Quick summary: IBC Tank 500L ICD - 500-litre capacity, virgin HDPE body, galvanised welded-mesh steel cage, DN50 discharge valve. Available in two configurations: vertical and horizontal. 2-year warranty, nationwide delivery in 1-3 business days, full VAT invoice.
1. Technical Specifications
| Specification | Detail |
|---|---|
| Product Code | ICD-IBC-500-NEW |
| Tank Material | Virgin HDPE |
| Capacity | 500 litres |
| Protective Cage | Galvanised welded-mesh steel |
| Discharge Valve | DN50 ball valve (standard) |
| Fill Cap | DN150 vented cap |
| Origin | Made in Vietnam |
| Warranty | 2 years |
Full VAT invoice available. In-stock, nationwide delivery in 1-3 business days.
2. IBC Tank 500L Configurations
The ICD IBC Tank 500L is available in 2 configurations to suit different operational requirements:
| Type | Dimensions (L x W x H mm) | Best Suited For |
|---|---|---|
| 500L Vertical | Contact us for exact dimensions | Standard warehouse storage; easy forklift access from both sides; smaller floor footprint than 1000L units |
| 500L Horizontal | Contact us for exact dimensions | Vehicle-mounted installation; gravity-feed systems; lower centre of gravity for stability in transit |
Contact ICD to confirm exact dimensions, leg options and stock availability for each configuration.
3. Applications
- Storage and transport of water, liquid food products (cooking oil, juice, syrup)
- Industrial and agricultural chemical containment
- Vehicle-mounted liquid transport (horizontal configuration)
- Gravity-feed water supply for irrigation systems
- Liquid raw material storage where 1000L capacity is not required
See also: IBC Tank 1000L - larger capacity option from ICD Vietnam.
4. Frequently Asked Questions
What is the difference between the vertical and horizontal types?
The vertical type is designed for standard warehouse storage with easy forklift access on two sides and a smaller floor footprint than a 1000L unit. The horizontal type has a lower centre of gravity, making it ideal for vehicle mounting or gravity-feed systems.
What material is the tank made from?
The inner container is virgin HDPE - chemically inert and food-safe. The outer cage is galvanised welded-mesh steel for structural strength and corrosion resistance.
What are the standard valve and cap specifications?
A DN50 ball valve at the discharge port and a DN150 vented cap on top. Butterfly valves and quick-connect fittings are available on request.
Can the tanks be stacked?
Yes, within the stacking load limits for each configuration. Contact ICD to confirm the stacking specifications for your chosen type.
What is the warranty period?
2 years from the date of purchase, covering manufacturing defects under normal operating conditions.
