The Xilin SDJAS500 and SDJAS1000 are adjustable-fork high-lift hand stackers from ICD, rated at 500 kg and 1,000 kg respectively, both lifting up to 1,600 mm. Imported as complete units from the Ningbo Ruyi group (Japanese quality standards) and distributed exclusively by ICD Vietnam, they carry a 2-year manufacturer warranty and use hydraulic operation for raising and moving loads.
1. Product Specifications
| Specification | Details |
|---|---|
| Load Capacity | 500kg |
| Max Lift Height | 1600 mm |
| Certification | CE, ISO 9001 |
| Brand | Xilin (Ningbo Ruyi Joint Stock) |
| Origin | China (Ningbo Ruyi) |
| Warranty | 2 years - ICD Vietnam authorized distributor |
| Fork Dimensions (T/W/L) | 48/100/800(1060) mm |
| Overall Width | 1500 mm |
| Machine Weight | 223 Kg |
2. Applications & Key Advantages
- Lifting and moving loads up to 500 kg (SDJAS500) or up to 1,000 kg (SDJAS1000)
- Logistics warehouses moving consumer goods, food and pharmaceutical pallets from trucks into storage
- Manufacturing plants transferring material pallets between production lines
- Supermarkets and retail stores stocking shelves and moving cartons
- Transport companies loading and unloading containers and trucks at ports and depots
- Mechanical workshops moving steel blanks, small machinery and heavy parts
- Small to medium warehouses needing a compact, easily adjustable stacker
Browse the full High-Lift Hand Pallet Trucks range from ICD Vietnam.
3. Product Images
4. Frequently Asked Questions
What is the difference between the two models?
The SDJAS500 is rated at 500 kg and the SDJAS1000 at 1,000 kg; both lift up to 1,600 mm.
What is the maximum lift height?
Both models raise loads up to 1,600 mm from the original position.
Can the forks be changed?
Yes. The forks can be changed easily to suit different load types.
What are the machine weights?
The SDJAS500 weighs 223 kg and the SDJAS1000 weighs 294 kg.
How are the units operated?
Insert the forks under the load, raise it with the hydraulic hand pump, move the stacker, lower the load and withdraw the forks. Foot and hand lift functions ease operation.
