The Export Plastic Pallet ICD-PLX-131113-BK measures 1300 x 1100 x 130 mm. It weighs 11.5 kg. It has a static load of 3,000 kg and a dynamic load of 1,000 kg.
1. Specifications of the Export Plastic Pallet ICD-PLX-131113-BK
| Specification | Details |
|---|---|
| Product code | WLV1113A3 |
| Dimensions | 1300 x 1100 x 130 mm |
| Static load | 3,000 kg |
| Dynamic load | 1,000 kg |
| Racking load | Not published by ICD |
| Weight | 11.5 kg |
2. How to Read the Load Ratings of This Pallet
Under ISO 8611, static load is the mass a pallet carries when it rests on a flat floor (3,000 kg for this code); dynamic load is the mass it carries while a forklift or hand pallet truck moves it, so the figure is lower (1,000 kg); ICD has not published a racking load for this code. The full definitions are on the ISO 8611-1 standard page. If the pallet will go on a racking, ask ICD before ordering rather than inferring a racking load from the static figure.
One pallet covers 1.43 m² of floor, so a layer of 100 pallets covers about 143 m².
Browse the full Export Plastic Pallets range from ICD Vietnam.
3. Comparison with Other 1300x1100 mm Pallets from ICD
The table lists ICD pallets with the same 1300x1100 mm footprint and the figures ICD has published. "Not published" means the product page has no figure.
| Product code | Height | Static load | Dynamic load | Weight |
|---|---|---|---|---|
| WLV1113A3 (this page) | 130 mm | 3,000 kg | 1,000 kg | 11.5 kg |
| N4-1311SL2 | 140 mm | 4,000 kg | 1,625 kg | Not published |
4. Product Images
5. Frequently Asked Questions
How many kg can the WLV1113A3 carry?
ICD publishes a static load of 3,000 kg and a dynamic load of 1,000 kg. ICD has not published a racking load for this code, so ask ICD first if you plan to use a rack.
How much does the WLV1113A3 weigh?
It weighs 11.5 kg according to the specification ICD publishes.
