The ICD-SW-S800E is a horizontal stretch wrapping machine from ICD Vietnam, built for wrapping long products that vertical pallet wrappers cannot handle - plastic pipes, steel bars, sections, aluminium frames and bundled materials. The product is conveyed through a rotating 800 mm wrapping ring that applies PE film continuously along its full length, with a throughput of roughly 15-30 metres per minute. Made in Vietnam, two-year warranty.
1. Product Specifications
| Specification | Details |
|---|---|
| Product code | ICD-SW-S800E |
| Origin | Vietnam |
| Warranty | 2 years |
2. Applications & Key Advantages
- Construction materials such as PVC and PPR pipes, aluminium profiles, steel sections and coiled steel sheet bundled together
- Wood and furniture production, including MDF and HDF panels cut into long strips, table legs and bed frames
- Electrical and electronics goods such as power cable reels, network cable and electrical conduit, wrapped against dust and moisture
- Export goods in containers, where any long product needs protective wrapping before loading
- Long items that standard vertical wrappers cannot process due to turntable size limits
- Continuous automated wrapping as products are pushed through the rotating ring
- Products up to 600 mm in diameter, with no limit on length
- Adjustable wrapping for different items via PLC programs stored on the touchscreen control
Browse the full Stretch Wrapping Machines range from ICD Vietnam.
3. Product Images
4. Frequently Asked Questions
What is a horizontal stretch wrapping machine and why is it needed?
A standard pallet wrapper works on a vertical axis using a turntable, which cannot handle long goods such as pipes or steel bars. The horizontal S800E lays the product flat and pushes it through a rotating wrapping ring, coating the entire length with PE film automatically.
What product sizes does the ICD-SW-S800E accept?
It uses an 800 mm wrapping ring and accepts products up to 600 mm in diameter, with no limit on length. The conveyor speed is adjustable from 0 to 15 metres per minute and the ring speed from 0 to 80 rotations per minute.
What film does it use?
It runs PE stretch film 100-500 mm wide and supports pre-stretch up to 200 percent to reduce film consumption.
Can the machine be customised?
Yes. Unlike fixed-size pallet wrappers, the S800E is usually configured around the conveyor length to suit the product and plant space, with options such as support rollers, automatic end-detection sensors and an automatic film cutter.
How is the machine controlled and powered?
It is controlled by a PLC with a touchscreen that stores multiple wrapping programs, and runs on a 380V / 50Hz / 3-phase supply.
