The Warehouse Storage Pallet ICD-PLK-136136-BK measures 1360 x 1360 x 160 mm. Colors: grey, blue. It has a static load of 6,000 kg and a dynamic load of 1,000 kg and a racking load of 700 kg. Material: HDPE.
1. Specifications of the Warehouse Storage Pallet ICD-PLK-136136-BK
| Specification | Details |
|---|---|
| Product code | H1313D4-1A |
| Dimensions | 1360 x 1360 x 160 mm |
| Forklift | 4-way entry |
| Low hand pallet truck | 4-way entry |
| Static load | 6,000 kg |
| Dynamic load | 1,000 kg |
| Racking load | 700 kg |
| Weight | Not published by ICD |
| Material | HDPE |
| Color | Grey, Blue |
2. How to Read the Load Ratings of This Pallet
Under ISO 8611, static load is the mass a pallet carries when it rests on a flat floor (6,000 kg for this code); dynamic load is the mass it carries while a forklift or hand pallet truck moves it, so the figure is lower (1,000 kg); racking load is the mass it carries on a rack, supported only at the ends (700 kg). The full definitions are on the ISO 8611-1 standard page. If the pallet will go on a racking, ask ICD before ordering rather than inferring a racking load from the static figure.
One pallet covers 1.85 m² of floor, so a layer of 100 pallets covers about 185 m².
Browse the full Warehouse Storage Pallets range from ICD Vietnam.
3. Product Images
4. Frequently Asked Questions
How many kg can the H1313D4-1A carry?
ICD publishes a static load of 6,000 kg and a dynamic load of 1,000 kg and a racking load of 700 kg.
What lifting equipment can be used?
As listed by ICD: a forklift with 4-way entry; a low hand pallet truck with 4-way entry.
Can I order a specific color or print a logo?
ICD lists these colors for this code: grey, blue. Please contact ICD for the conditions.
