The PL08-3 is the black version of the PL08 cold-store pallet, 1200x1000x145 mm. At 145 mm tall, 5 mm lower than the 150 mm standard, it optimises tier height in multi-level cold rooms. It carries a 2,000 kg static load and 1,000 kg dynamic load, with 20 anti-slip studs spread across the deck. It weighs 11.5 kg and is moulded in HD/PP to ISO 9001:2015.
1. Product Specifications
| Specification | Details |
|---|---|
| Product code | ICD-PL1210145-CB |
| Dimensions (mm) | 1200 x 1000 x 145 |
| Dynamic load (kg) | 1000 |
| Static load (kg) | 2000 |
| Material | HD/PP plastic |
| Color | Black |
2. Applications & Key Advantages
- Multi-tier fixed-height cold-room racking, using the 145 mm height to gain vertical space
- WMS colour-coding, with the distinctive black colour separating it from lighter pallets
- Japanese and Korean FDI production lines using the 1200x1000 mm racking standard
- Dedicated cold-store operations needing a light 11.5 kg black pallet for system consistency
- Cold storage for seafood and frozen foods, with freeze-resistant HD/PP that resists brittleness and deformation
- HACCP-compliant food and GMP-compliant pharmaceutical warehouses using disinfectant-resistant HD/PP
- Export use without ISPM-15 fumigation
- Manual handling in cold environments where staff wear thick protective gear
- Goods needing 20 anti-slip studs to secure loads on wet or uneven floors
- Asset tracking through custom logo and company-name printing
Browse the full Warehouse Storage Pallets range from ICD Vietnam.
3. Product Images
4. Frequently Asked Questions
What are the dimensions and material of the PL08-3?
It measures 1200 x 1000 x 145 mm and is moulded in HD/PP to ISO 9001:2015, in black.
What loads can it carry?
A static load of 2,000 kg and a dynamic load of 1,000 kg.
Why is the 145 mm height useful?
Being 5 mm lower than the 150 mm standard, it frees up vertical space in fixed-height multi-tier cold rooms.
Is it suitable for cold storage?
Yes. Its freeze-resistant HD/PP does not become brittle or deform at deep sub-zero temperatures.
How much does it weigh?
It weighs about 11.5 kg, the lightest in the PL08 line, easing manual handling in cold environments.
