The PL12-LK is the highest-capacity pallet in ICD's red range, measuring 1200x1000x150 mm, with a static load of 5,000 kg and a dynamic load of 2,400 kg - well above most same-size pallets on the market. The distinctive red colour aids colour-coded warehouse management. It weighs 21 kg, is made from virgin HDPE to ISO 9001:2008, and supports two-way high-lift hand pallet trucks.
1. Product Specifications
| Specification | Details |
|---|---|
| Product code | PL12-LK |
| Dimensions (mm) | 1200 x 1000 x 150 |
| Dynamic load (kg) | 2400 |
| Static load (kg) | 5000 |
| Material | HDPE |
2. Applications & Key Advantages
- The 2,400 kg dynamic load suits high-speed electric forklifts in automated warehouses and heavy industrial distribution running multiple shifts
- The distinctive red colour supports visual sorting in colour-coded warehouse management systems for fast area or product identification
- Two-way high-lift hand pallet truck support allows loading onto high selective racks without a powered forklift
- Single-deck design with transverse runners and four-way machine and low-lift forklift access
- Suited to heavy industrial goods needing high dynamic capacity
- Virgin HDPE is durable, waterproof and easy to clean
- 100% recyclable with optional logo and company-name printing
- Produced to ISO 9001:2008
Browse the full Warehouse Storage Pallets range from ICD Vietnam.
3. Product Images
4. Frequently Asked Questions
What are the dimensions and load ratings of the PL12-LK?
It measures 1200x1000x150 mm with a 5,000 kg static load and a 2,400 kg dynamic load.
Why is the PL12-LK red?
The distinctive red colour supports colour-coded warehouse management, helping staff quickly identify storage areas or product types.
What forklift types does it support?
Four-way low-lift hand truck and electric forklift access, plus two-way high-lift hand pallet truck support.
What is its weight and material?
It weighs 21 kg and is made from virgin HDPE to ISO 9001:2008.
What applications suit its high capacity?
High-speed electric forklift operation in automated warehouses and heavy industrial distribution running multiple shifts.
Compare with ICD's other warehouse storage pallets
ICD Vietnam's LK series covers a range of load ratings and footprints for warehouse use:
| Model | Dimensions | Dynamic / Static load | Key feature |
|---|---|---|---|
| PL05-LK | 1200x1000x150mm | 1000kg / 4000kg | Standard one-piece moulded pallet |
| PL12-LK (this product) | 1200x1000x150mm | 2400kg / 5000kg | Highest-capacity pallet in ICD's red range |
| PL09-LK | 1100x1100x150mm | 1000kg / 3000kg | Floor-deck design, square footprint |
| PL01-LK | 1200x800x180mm | 1000kg / 4000kg | Taller 180mm profile, one-piece moulded |
| PL04-LK | 1200x1000x150mm | 1000kg / 4000kg | Lightweight floor-deck design |
Additional FAQ
Why is PL12-LK rated for higher loads than PL05-LK despite the same footprint?
Both share the 1200x1000x150mm footprint, but PL12-LK is reinforced for a higher 5000kg static / 2400kg dynamic load rating - choose it when your goods exceed PL05-LK's 4000kg/1000kg capacity.
