ICD Vietnam’s lift table range has three product lines, rated from 150 to 1,500 kg, with platforms that raise to 740-1,500 mm: the SP150 manual lift table, the DP30/DP50 electric lift tables and the EU SP800/SP1000/SP1500 manual lift tables. These are mobile scissor lift tables for warehouses and workshops, not office desks. The SP150 lists at 8,600,000 VND; the other models are quoted to specification.
A lift table brings a load up to working height on the spot; it does not carry pallets over distance. For travel and stacking see the electric forklift range and the full forklift and handling range.
1. Specifications of the lift tables
Lift height is the maximum platform height; the platform is given as length x width x thickness. Models marked Contact are quoted on request.
| Model | Capacity | Max. lift | Platform (mm) | Weight | Lift drive | List price |
|---|---|---|---|---|---|---|
| SP150 | 150 kg | 740 mm | 740 x 450 x 35 | 44 kg | Foot pump | 8,600,000 VND |
| DP30 | 300 kg | 900 mm | 815 x 500 x 50 | 111 kg | Electric, 800 W | Contact |
| DP50 | 500 kg | 900 mm | 815 x 500 x 50 | 114 kg | Electric, 800 W | Contact |
| EU SP800 | 800 kg | 1,000 mm | 1,000 x 510 x 55 | 115 kg | Foot pump | Contact |
| EU SP1000 | 1,000 kg | 1,000 mm | 1,016 x 515 x 60 | 115 kg | Foot pump | Contact |
| EU SP1500 | 1,500 kg | 1,500 mm | 1,220 x 610 x 60 | 135 kg | Foot pump | Contact |
2. Manual and electric lift tables
A lift table works in two steps: a pump pushes hydraulic oil into the cylinder, the cylinder opens the scissor arms and the platform rises; opening the release valve lowers it. On the SP150 and the EU models the operator works a foot pedal. On the DP30 and DP50 a push button on the 800 W motor unit replaces the pedal.
3. Choosing by capacity, lift height and platform
Take the heaviest load plus its pallet or container, then choose a model rated above it with enough working height. The EU SP1500 has a 1,220 x 610 mm platform and lifts to 1,500 mm; the SP1000 has a 1,016 x 515 mm platform and lifts to 1,000 mm. A 1,200 x 1,000 mm pallet is wider than a 610 mm platform and overhangs on both sides, so long cartons, crates or narrow pallets are the better fit.
| Need | Suitable model | Figures behind it |
|---|---|---|
| Light loads up to 150 kg | SP150 | 44 kg, 740 x 450 mm platform, lifts to 740 mm |
| Electric lift, 300-500 kg | DP30, DP50 | 800 W motor, lifts to 900 mm |
| 800-1,500 kg, foot pump | EU SP800, SP1000, SP1500 | Platforms from 1,000 x 510 mm to 1,220 x 610 mm |
4. Operation and safety
According to the product pages, the models have lockable casters and an overload valve that protects the pump and the operator, and the EU models add a guard plate for the operator. Sequence of use:
- Place the load on the platform, roll the table to the spot and lock the casters.
- Pump the pedal or press the button to reach working height.
- Move the load off.
- Squeeze the release brake to lower the platform, then roll the table away.
These are load-handling tables and must not lift people. General rules for powered trucks are in forklift safety rules.
5. Related articles on lift tables
6. Frequently asked questions about lift tables
1. Which lift table is light for its capacity?
The SP150 weighs 44 kg and lifts 150 kg; the EU SP1500 weighs 135 kg and lifts 1,500 kg. The chart below divides each model’s capacity by its own weight.
2. Does the electric lift table run on mains power or a battery?
The product page gives only the 800 W motor rating, not the supply. Ask ICD for the power supply of the DP30 or DP50 before ordering.
3. Is there a 2 or 3 tonne lift table?
The largest model is the EU SP1500, rated 1,500 kg. Models from 2 tonnes are not in this range.
4. What warranty applies?
Lift tables carry a 12-month warranty from the sale date under ICD’s warranty and repair policy.
